| High Light: | Septic Pump Truck,Sewage Pumping Trucks |
||
|---|---|---|---|
4m3 - 16m3 Sewage Sewage Suction Truck Dumping System With High Pressure Italian Jurop
Our advantages:
1: SINOTRUk HOWO 6x4 sewage suction truck howo tanker truck low price for sale
2: Our trucks have a strong engine and strong frame that can fit in all kinds of road conditions.
3: This truck is special for liquid waste.
4: All color is optional for your reference.
|
Sinotruk Howo 6x4 Vacuum Truck – 15 CBM |
|
|
Chassis Model |
ZZ1257M4647C (Left Hand Driving Type) |
|
Production Year |
2015, new truck. |
|
Cabin |
HW76 cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn,air conditioner , with transverse stabilizer,with 4-point support fully floating suspension + shock absorber. |
|
Engine |
Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.87, 290HP, Euro 2 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 11.592 L |
|
Transmission |
HW15710, 10F & 2R. Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2) |
|
Steering |
ZF power steering, modol ZF8118, hydraulic steering with power assitance |
|
Front Axle |
HF9, 1x9000 KGS, Drum Brake Steering with doubleT-cross section beam |
|
Rear Axle |
HC16, 2x16000 KGS Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles. Ratio:4.8 |
|
Propeller Shaft |
Double universal joint propeller shaft with gear-shaped coupling flange |
|
Chassis |
Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer |
|
Brake |
Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake |
|
Electrics |
Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
|
Tyres |
12.00R20, radial tyres with one spare tyre |
|
Fuel Tank |
400L |
|
Suction Sewage Tank |
15 CBM, with rear back hole, and anti-static, with Jurop Vac. Pump PN84D |
|
Overall Dimension |
8800*2550*3200 mm |
