Product Details:
Payment & Shipping Terms:
|
| Driving Mode: | 4x2 | Dimension: | 6980x2496x3150mm |
|---|---|---|---|
| Bucket Volume: | 12 CBM | Loading Weight: | 7920KG |
| High Light: | rear load garbage truck,garbage truck collection |
||
1. Material of bucket is T520 High Strength , assure the quality
2.Very Stable Seal System prevent leakage
3. Hydraulic Valve inported from Italy ,keep excellent performance
|
Condition: |
New |
Drive Wheel: |
4x2 |
Type: |
Recycling |
|
Transmission Type: |
Manual |
Emission Standard: |
Euro 2 |
Volume: |
3001 - 6000L |
|
Fuel Type: |
Diesel |
Engine Capacity: |
8L |
Size: |
6125x2140x2600 mm |
|
Gross Vehicle Weight: |
32000 |
Place of Origin: |
Shandong |
Brand Name: |
SINOTRUK |
|
Model Number: |
ZZ1167M4611W |
Certification: |
CE |
After-sales Service |
Overseas service |
|
Color: |
White,Red,Blue,Black,Yellow,Option |
||||
|
Dimension(LxW xH)(unloaded)(mm) |
6980x2496x3150 |
|||
|
Cargo body capacity (LxWxH)(mm) |
12m³ |
|||
|
Hydraulic system working pressure(Mpa) |
20 |
|||
|
A cycle time filling job (s) |
≤25 |
|||
|
A waste of time shift (s) |
≤45 |
|||
|
Maximum crushing compression strength (kg) |
>35000 |
|||
|
Wheel base (mm) |
3800 |
|||
|
Max speed(km/h) |
75 |
|||
|
Curb weight(kg) |
7950 |
|||
|
Loading Weight(kg) |
7920 |
|||
|
Engine |
Model |
WD615.87,water-cooled,four strokes, |
||
|
Fuel type |
Diesel |
|||
|
Power,max(kw/rpm) |
213/2200 |
|||
|
Emission |
EUROII |
|||
|
Fuel tanker capacity (L) |
300 |
|||
|
Transmission |
Model |
HW15710,10 forward& |
||
|
Brake system |
Service brake |
Dual circuit compressed |
||
|
Parking brake |
spring energy, compressed |
|||
|
Steering system |
Model |
ZF8098 |
||
|
Front axle |
Steering with double T-cross section beam |
|||
|
Rear axle |
Pressed axle housing,central double |
|||
|
Tyre |
12.00-20 |
|||
|
Electrical system |
Battery |
2X12V/165Ah |
||
|
Alternato |
28V-1500kw |
|||
|
Starter |
7.5Kw/24V |
|||
|
Cab |
HW70 |
|||
Other Truck can be provide according to your request, freely contact me for the informations and quotations.
