Product Details:
Payment & Shipping Terms:
|
Application: | Boats Hydraulic System | Direction Of Rotation: | Clockwise |
---|---|---|---|
Feature: | Low Noise | Mounting Flange: | SAE 2 Hole |
Power: | Hydraulic | Pressure: | High Pressure |
Seals: | Perbunan | Structure: | Piston Pump |
Highlight: | flow control pump |
Clockwise Rotation Small volume Tandem Hydraulic Pump , 18cc Displacement
Quick details
Tandem Hydraulic Pump
Clockwise Rotation
High Pressure
Splined shaft
for Hydraulic system. Ship Hydraulic system
Clockwise Rotation High Pressure Tandem Hydraulic Pump
Axial piston pump, displacement is 18cc.
Pressure and Flow control
Clockwise Rotation
Perbunan seals
Splined shaft
SAE 2 hole UNC inch thread
Thru-drive Rear Cover, can connect another pump
Specifications:
Specifications: |
|
|
|
16/18 |
28 |
45 |
71 |
100 |
140 |
Displacement |
|
Vg max |
cm3 |
18 |
28 |
45 |
71 |
100 |
140 |
Max speed |
|
nmax |
rpm |
3300 |
3000 |
2600 |
2200 |
2000 |
1800 |
Max. flow |
in nmax |
qv |
L/min |
59.4 |
84 |
117 |
156 |
200 |
252 |
in 1500 r/min |
27 |
42 |
68 |
107 |
150 |
210 |
|||
Max. power (Δp=280bar)
|
in nmax |
Pmax |
Kw |
27.7 |
39 |
55 |
73 |
93 |
118 |
in 1500 r/min |
12.6 |
20 |
32 |
50 |
70 |
98 |
|||
Max. torque (Δp=280bar)
|
in Vg max |
Tmax |
Nm |
80.1 |
125 |
200 |
316 |
445 |
623 |
Weight |
|
m |
Kg |
12 |
15 |
21 |
33 |
45 |
60 |
Applications:
Hydraulic system. Ship Hydraulic system.
Advantage:
Good quality, Competitive price and quick delivery.
Low noise, SmallVolume
