High Pressure Special Purpose Vehicles , 30° Left And Right Flexible Road Washer

large.img.alt
small.img.alt

Large Image :  High Pressure Special Purpose Vehicles , 30° Left And Right Flexible Road Washer

Product Details:
Place of Origin: China
Brand Name: XCMG
Certification: ISO
Model Number: DFLll60BX2
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiate
Packaging Details: Ro-Ro
Delivery Time: 30-50 days
Payment Terms: 50% deposit, balance before shipment
Supply Ability: 10000pcs/year
Detailed Product Description
Chassis Model: DFLll60BX2 Deputy Engine Model: JX493G3
Spray Rack Cleaning Width: 2.5-3.5m Spray Rack Declination: 30°Left And Right
High Pressure Cleaning Capacity: 25000m2/h Highest Cleaning Water Pressure: 10MPa
Water Gun Range: 38m The Jug Actual Volume: 7.52L
Condition: New
High Light:

Rescue Tow Truck

,

Road Wrecker Truck



High Pressure Special Purpose Vehicles, 30° Left And Right Flexible Road Washer





Specifications:



Chassis model

DFLll60BX2

Deputy Engine Model

JX493G3

Spray rack cleaning width

2.5-3.5m

Spray rack declination

30°Left and Right

High pressure cleaning capacity

25000m2/h

Highest cleaning water pressure

10MPa

Clean water flow

134L/min

Spray water flow

134L/min

Low pressure sprinkler flow

600~800L/min

Low pressm'e flushing width

≥24m

Water gun range

38m

The jug actual volume

7.52L

Dimensions(L*W*H)

9000*2495*3030mm





Description:



Street cleaning vehicle is use for clean and maintenance of the city pavement, vendor's stand and clean the pasted advertisements, has the fuction of high pressure water line cleaning, point cleaning and handcart inject cleaning. The vehicle has the signature of all electrical automatic control, small turn radius, good performance of access, and clean deeply, apply in the nerrow street and pavement, square which are hard to enter with the big vihicles.





Competitive Advantage:



1. Before spray rack with a high pressure cleaning maximum cleaning width up to 3.5 m; cleaning high  pressure, low flow,  strong decontamination, efficient water-saving, the antiquated road stains can be cleaned.

2. The left and right high pressure angle spray cleaning of curbs, sidewalks and fence isolated area.

3. The high pressure spray guns can also clean the road signs, billboards, elevated road etc.

4. Spray system with powerful spraying dust, spraying air disinfectant function and regulation of air humidity.

5. Low pressure water system, dual stage impeller centrifugal pumps, high efficiency sprinkler width, long range water gun, also the optional green watering and self-absorption feature.

6. High pressure pumps, nozzles, high pressure spray gun, critical hydraulic and electrical originals of this truck adopt international famous brand name products, with excellent performance, reliable operation.
